SECONDARY OIL CONTAINMENT SYSTEM

OILBLOCKER™ PLUS TRANSFORMER CONTAINMENT

OilBlocker Plus Oil Spill Containment System uses Albarrie’s smart fabric technology. The innovative smart fabric and containment design proactively protects against oil spills and leaks around mineral oil-filled transformers.

24/7 SPILL PROTECTION FOR SMALL TRANSFORMERS

A little oil creates a lot of environmental damage. Even though the equipment is small, protection against chronic oil leaks and catastrophic spills is still required. Albarrie’s OilBlocker™ Plus Oil Spill Containment System provides the required protection at a fraction of the cost compared to other traditional oil containment systems.

OilBlocker™ Plus Oil Spill Containment System is a layered containment designed to trap and lock mineral oil around oil-filled equipment. The containment system still allows water to flow freely through its vertical walls, keeping the containment virtually maintenance-free. OilBlocker™ Plus is quick and inexpensive to install, as a result, companies will meet SPCC regulations for secondary containment.

Smart Containments In Action

Our Smart Containments In Action comparison guide gives you an inside view at how our systems stack up against other products in the market. Discover how our systems can save you time and money.



Key Benefits

Virtually Maintenance Free

No pumps required. Albarrie’s smart fabric traps oil, not water.

Environmentally Compliant

Meets EPA Secondary Containment requirements for SPCC 40 CFR 112.7 and IEEE Std. 980.

Budget-Friendly

Reduce installation and maintenance costs compared to other transformer oil containment systems.

Flexible Design

Designed and installed in greenfield or brownfield applications for all soil types within any geometric configuration.

Product Details

SMART FABRIC TECHNOLOGY

Albarrie’s transformer secondary oil containment systems and oil-spill containments use patented mineral oil-reactive self-sealing smart fabric technology known as Oilmat. The smart fabric contains a unique proprietary blend of dense oil-immobilizing polymers, called Alabsorb, needle-punched between two nonwoven fabric layers that seal on contact with oil, not water.

TRAP OIL, NOT WATER

When mineral oil contacts the polymers, they undergo a chemical change. This chemical change congeals and seals the oil between the geotextiles, turning it into an impassable membrane, keeping the oil inside the containment area.

SHALLOW EXCAVATION

OilBlocker Plus™ doesn’t require a deep excavation for underground installation. The pit area is fitted with an impermeable geotextile fabric that keeps all fluids within the containment area, allowing the Oilmat walls to drain water while immobilizing oil.

UNFAZED BY RELENTLESS ELEMENTS

Traditional concrete secondary oil containment systems aren’t ideal for severe weather, such as heavy rainfall, snow, ice, and freezing temperatures. There’s a high risk of water overflowing and mechanical pumps failing. Fortunately, due to the free-draining ability of Albarrie’s smart fabric, you never need to worry about severe weather.

QUICK & EASY INSTALLATION

Our systems are installed without interruption of service in either brownfield or greenfield applications. They come complete with all materials required for assembly. They can be installed by your organization or your preferred contractor under Albarrie’s guidance or by our professional services team.

DESIGN AND INSTALLATION GUIDELINES

Albarrie ensures your project is successful and goals are achieved through a consultative process. Aside from following client specifications, our standard designs include:

  • Site plan drawings for 110% containment volume
  • A civil materials takeoff list
  • Products are designed to meet SPCC Rules and IEEE guidelines for secondary oil containment.

Information provided by Albarrie on this website (the "Site") is for general information purposes only. All information on the Site is provided in good faith, however Albarrie makes no representation or warranty of any kind, express or implied, regarding the accuracy, adequacy, validity, reliability, availability or completeness of any information on the Site. Products may not work as advertised or perform differently based on application, operating conditions, and depend on chemical, thermal, and humidity and other factors.

Options

Below Ground Design
Multiple transformers at an electrical substation showing Albarrie's Esterweb containment underneath.
Grouped Equipment Containment Design

Connect With Our Team

Applications

Installation of Sorbweb Secondary Containment System at an electrical substation near the mountains and ocean in British Columbia.
Environmentally-Sensitive Areas
Solar and windmilll farm near mountains
Solar and Wind Farm Containment Systems
Small neighbourhood transformer with spill tray for transformer secondary containment
Small Oil-Filled Transformers
Multiple transformers at an electrical substation showing Albarrie's Esterweb containment underneath.
Multiple Above-Ground Transformers
